CASTOS-15
NEW
- overview
- specifications
- technology
Suitable for high-performance mountain
bikes, with 2.1 inch tire; forged aluminum crown + magnesium alloy lower leg,
diameter 32mm, high-strength lightweight aviation-grade aluminum stanchion,
newly upgraded air suspension system, bearing-type sliding sleeve, the
stanchion is extremely smooth; Optional coil spring suspension fork (using high
carbon steel stanchion), optional full-featured; easy to control various
complex road conditions, easy to maintain.
| MODEL: | A-TNL | A-TNL-R | A-RL | A-RL-R | TNL-P | RL-P |
|---|---|---|---|---|---|---|
| STEERER | Aluminum 7075/Steel Ø30(39.8)*28.6 | |||||
| CROWN PITCH | P130mm | |||||
| CROWN | Aluminum | |||||
| STANCHION | Aluminium- Ø32mm hard Anodize |
Steel-Ø32mm CP/QPQ | ||||
| CASTING | Magnesium 100*15mm Thru Axle | |||||
| SPRING | Air | Coil w/P | ||||
| WHEEL SIZE | 27.5" 29" | |||||
| TRAVEL | 100/120mm | |||||
| BRAKE TYPE | Disc Brake 27.5" 160/180mm 29" 180/203mm | |||||
MAX TIRE | 2.6 Inch | |||||
- A: Air
- R: Rebound
- P: Preload Adjuster
- RL: Remote Lock-out
- TNL: Hydraulic Lock-out
