FIX -DH
NEW
- overview
- specifications
- technology
Suitable for leisure and lightweight high-performance mountain bikes, magnesium alloy lower leg + forged aluminum crown; high-strength and lightweight aerospace-grade aluminum 34mm stanchion , bearing-type sliding sleeve, stanchion smoothness UP; newly upgraded air shock absorber system + 2.6/3.0inch Tire, 110-15mm thru-axle , 80-140mm travel.
| MODEL: | A-TNL | A-TNL-R | TNL-R | TNL-P |
|---|---|---|---|---|
| STEERER | Aluminium/Steel /30*28.6 | |||
| CROWN PITCH | P145mm | |||
| CROWN | Aluminum | |||
| STANCHION | Aluminium-Ø34mm hard Anodize Steel-/34mmCP/QPQ | |||
| CASTING | Magnesium Open Dropout 110*9.8mm (*Thru axle 110*15mm) | |||
| SPRING | Air Spring Coil spring | |||
| WHEEL SIZE | 20“ 24“ 27.5“ 29“ (*27.5" 29") | |||
| TRAVEL | 80/100/120/140mm | |||
| BRAKE TYPE | Disc Brake 20"24"160/180mm / 27.5"29"180/203mm | |||
MAX TIRE | 20" 24" 3.0 Inch / 27.5" 29" 2.6 Inch | |||
- A: Air
- R: Rebound
- TNL: Hydraulic Lock-out
- P: Preload Adjuster
