ARES-DH
NEW
- overview
- specifications
- technology
Suitable for electric bicycles and
high-performance mountain bike downhill bikes, magnesium alloy lower leg +
forged aluminum crown; high-strength and lightweight aerospace-grade aluminum
36mm stanchion, bearing-type sliding sleeve, add points to the smoothness of
the stanchion ; newly upgraded air suspension system + with 2.8 inch tire, easy
to deal with various complex road conditions, easy to maintain.
| MODEL: | A-TNL | A-tnl-R | TNL-P |
|---|---|---|---|
| STEERER | Aluminium 7075,Ø30*28.6 | ||
| CROWN PITCH | P145mm | ||
| CROWN | Aluminum | ||
| STANCHION | Aluminium-Ø36mm hard Anodize | ||
| CASTING | Magnesium 110*Ø15mmt Thru Axle | ||
| SPRING | Air Spring Coil Spring | ||
| WHEEL SIZE | 27.5+" 29+" | ||
| TRAVEL | 100/120/140/160mm | ||
| BRAKE TYPE | Disc Brake (180mm-203mm) | ||
MAX TIRE | 2.8 Inch | ||
- A: Air
- R: Rebound
- TNL: Hydraulic Lock-out
- P: Preload Adjuster
